• Circular screens ranging from 6mm to
1000mm diameter.
• Uniformly cut by specially developed
power press, to avoid uneven edge.
• Absolutely no
wastage.
• Specially processed to withstand high pressure
and heat.
• High open area / flow rate.
• Closely
controlled, accurate apertures.
• Smooth surface - screening surface has no sharp
edges, burrs or acute angles. |
|
• Highly reusable and economical too.
•
High durability - self-supporting.
• Stable under tension.
• Suitable as support for less rigid media.
• Computer
controlled production.
• Also available in customized
size.
• High quality 304L stainless steel wire mesh
cleaned by ultrasonic process. | |
 |
|
• Spot Welded Multilayer packs, assembled in
proper sequence to eliminate operator error.
• Available in
any size & combination of meshes.
• Highly
User-Friendly.
• Extra strong, sturdy and convenient for
problem free processing.
• High durability.
• High
physical & chemical resistance.
• Screen pack prevents
any contamination (foreign particles) in the molten mass from
going through extrusion process.
• The edges are
spot-welded instead of aluminium framing to impart strength
for durability.
• An efficient import substitute.
•
Multilayer circular screen serve two purpose. The spot welded
acts as a spot around the edge of the screen, there by prevent
"BLOW BY" and prevents any loose wires from entering the flow of polymers.
| |
 |
|
• Also known as candle filters, these screen
packs are used in multilayer film and lamination plants.
•
Available in various combinations of meshes to suit your need.
• Available in various customized models.
• The edges are spot-welded for lasting
strength
| |
 |
|
Ambica offers both weaves in Multimesh
circular screen, Plain-Dutch weave & Twilled-Dutch Weave.
Specially used in BOPP film plant, woven sacks,
PET &
non woven fabric plant.
PLAIN-DUTCH WEAVE
:
The pattern of this mesh is the same as in plain
weave e x cept that the warp wires one of a larger diameter
than the shute wires and the shute wires are driven up close
to each other, resulting intaperes or wedge-shaped opening
instead of square opening. In dutch weave the warp wires
remain in straight conditions and the shute wires are
crimped.
TWILLED-DUTCH WEAVE :
Wire
cloth which has the same pattern as twilled weave e x cept the
warp wires are of a larger diameter than the shute wires &
the shute wires are driven up tapers or wedge-shaped opening.
Warp wires remain in a straight condition, but the shute wires
take all the crimp. Due to the twilled weave construction, the
shute wires are not only deformed in depth (crimps when formed around the warp wires) but also
sideways. | |
 |
|
• Cut elements, available in any design and style in single
or multiple layers.
• With or
without spot welding
| |
 |
|
• Protects plastic extruders and molding
machine against iron contamination such as Nails, Nuts, Iron
Bits etc.
• High power magnetic tubes are provided.
•
Various Shapes Circular, Square or Rectangular - are available
to match the size and shape of the Hopper Precision made as
per your requirements.
• Fabricated in Stainless
Steel.
• Precision making as per
your specification as well.
| |
 |
|
Some machines have specially designed shapes for filters,
thus making it more customized so to increase the rapport
between the machine manufacturers and the customers but here
in Ambica special designer screens
have been developed to suit the customers both in the quality
and service point of view.
| |
 |
|
• AMBICA group specializes in manufacturing
and supplying of 304L high quality stainless steel wire mesh
and wire cloth products for domestic consumption as well as
for export to foreign countries.
• Ambica is proud to have
provided wire mesh and wire cloth products for the last 30
years to innumerable industries and
applications.
PLAIN SQUARE WEAVE
:
Plain Square Weave, the most common weave, with
the same diameter warp and shute wires woven in a simple over
and under pattern. It produces screens with the same mesh
count in both directions. Mesh woven in this pattern has the
maximum stability
The full
range of specification from 4 mesh to 500 mesh and up to 2
microns. | |
 |
|
Since last three decades our company has
been taking care of the basic quality control in the arena of
plastic and rubber industries. The products, Extruder Screens,
as they are fondly known in the market are the first among the
few elements in the extruder machines to filter the raw
materials. So it is definitely necessary to take care of the
quality of each of the product as it takes care of the
foundation of the quality.
Maintaining high standards
of quality control at every single stage of manufacturing with
the help of rigorous tests and regular inspections is a common
practice at AMBICA.
We are approved supplier of many
major plastic & rubber machinery manufacturers in India
and abroad.
Use it, Approve it, Suggest it- this is one
of the policies set by the company. Today this unbreakable law
is successfully promoting the product satisfactorily to the
clients.
The second strategy is QSP - Quality, Service,
Price. A euphemistic stress is put on the quality and there is
no compromise on that part. A specialized after sales service
is the forte of the company and
at last the price is a factor that cannot be compromised upon.
| |
 |
